FD1000 Core Drilling RigRequest Quote
Key Specifications
- BTW Drilling Capability: 1,200 m
- NTW Drilling Capability: 1,000 m
- HTW Drilling Capability: 800 m
- Maximum Powerhead Torque: 2,600 N·m
- Maximum Powerhead Speed: 1,400 rpm
- Lifting Force: 24 T
- Propulsive Force: 12 T
- Engine: 129/130 kW
- Drilling Angle: 45–90°
- Mounting: Steel-track crawler
- Operating Weight: 8.4 T
-
FD1200 Core Drilling RigRequest Quote
Key Specifications
- BTW Drilling Capability: 1,400 m
- NTW Drilling Capability: 1,200 m
- HTW Drilling Capability: 1,000 m
- Maximum Powerhead Torque: 3,000 N·m
- Maximum Powerhead Speed: 1,400 rpm
- Lifting Force: 26 T
- Propulsive Force: 12 T
- Engine: 132 kW
- Drilling Angle: 45–90°
- Mounting: Steel-track crawler
- Operating Weight: 9 T
-
FD800 Core Drilling RigRequest Quote
Key Specifications
- BTW Drilling Capability: 1,000 m
- NTW Drilling Capability: 800 m
- HTW Drilling Capability: 600 m
- Maximum Powerhead Torque: 2,000 N·m
- Maximum Powerhead Speed: 1,400 rpm
- Lifting Force: 20 T
- Propulsive Force: 10 T
- Engine: Yuchai 92 kW, six-cylinder
- Drilling Angle: 45–90°
- Mounting: Steel-track crawler
- Operating Weight: 7.5 T
-
FDG 400 Core Drilling RigRequest Quote
Key Specifications
- BTW Drilling Capability: 480 m
- NTW Drilling Capability: 400 m
- HTW Drilling Capability: 200 m
- Maximum Powerhead Torque: 1,200 N·m
- Maximum Powerhead Speed: 1,400 rpm
- Lifting Force: 16 T
- Propulsive Force: 8 T
- Engine: Yuchai 75 kW
- Drilling Angle: 45–90°
- Mounting: Steel-track crawler
- Operating Weight: 5.8 T
-
FDG 600 Core Drilling RigRequest Quote
Key Specifications
- BTW Drilling Capability: 650 m
- NTW Drilling Capability: 600 m
- HTW Drilling Capability: 300 m
- Maximum Powerhead Torque: 1,600 N·m
- Maximum Powerhead Speed: 1,400 rpm
- Lifting Force: 16 T
- Propulsive Force: 8 T
- Engine: Yuchai 91 kW
- Drilling Angle: 45–90°
- Mounting: Steel-track crawler
- Operating Weight: 6.2 T
-
FDG400 Full Hydraulic Waterwell Drilling RigRequest Quote
Key Specifications
- Maximum Drilling Depth: 800 m
- Hole Diameter: 140–400 mm
- Lifting Force: 28 T
- Equipped Capacity: 153 kW
- Swing Torque: 8,850–13,150 N·m
- Penetration Efficiency: 15–35 m/h
- Engine: Cummins
- Mounting Options: Crawler / Skid / Truck
- Operating Weight: 12 T
-
FDX 400 Core Drilling RigRequest Quote
Key Specifications
- BTW Drilling Capability: 480 m
- NTW Drilling Capability: 400 m
- HTW Drilling Capability: 200 m
- Maximum Powerhead Torque: 1,200 N·m
- Maximum Powerhead Speed: 1,400 rpm
- Lifting Force: 16 T
- Propulsive Force: 8 T
- Engine: Yuchai 75 kW
- Drilling Angle: 45–90°
- Mounting: Rubber-track crawler
- Operating Weight: 5.3 T
-
FDX 600 Core Drilling RigRequest Quote
Key Specifications
- BTW Drilling Capability: 650 m
- NTW Drilling Capability: 600 m
- HTW Drilling Capability: 300 m
- Maximum Powerhead Torque: 1,600 N·m
- Maximum Powerhead Speed: 1,400 rpm
- Lifting Force: 16 T
- Propulsive Force: 8 T
- Engine: Yuchai 91 kW
- Drilling Angle: 45–90°
- Mounting: Rubber-track crawler
- Operating Weight: 5.7 T
-
Request QuoteBrand: FYFDX400 Full Hydraulic Waterwell Drilling Rig
Key Specifications
- Maximum Drilling Depth: 800 m
- Hole Diameter: 140–400 mm
- Lifting Force: 28 T
- Equipped Capacity: 153 kW
- Swing Torque: 8,850–13,150 N·m
- Penetration Efficiency: 15–35 m/h
- Engine: Cummins
- Mounting Options: Crawler / Skid / Truck
- Operating Weight: 12 T
-
Request QuoteBrand: GOLDGD-1C Seismic Node
Product Features:
• High Sensitivity & Precision: Integrated digital sensors ensure accurate seismic signal detection.
• Wireless & Efficient: Cable-free design simplifies deployment and reduces operational costs.
• Durable Construction: IP-rated protection for use in rugged field conditions.
• Long Battery Life: Low power consumption for extended continuous recording.
• Flexible Applications: Ideal for 2D/3D seismic surveys, structural monitoring, and academic research.
• User-Friendly Software: Intuitive interface for setup, synchronization, and data retrieval. -
Request QuoteBrand: GOLDGD-5 Ultra Magnetotelluric System
Product Features
• Wideband Detection (DC–10 kHz): Delivers full-spectrum coverage for shallow and deep subsurface structures.
• High-Precision 32-bit ADC: Achieves crystal-clear signal fidelity with ultra-low noise and distortion.
• Multi-Mode Integration: Seamlessly supports MT, AMT, and CSAMT modes for flexible exploration needs.
• Real-Time Geological Imaging: View resistivity profiles, phase curves, and apparent resistivity instantly on-site.
• Rugged, Field-Ready Design: IP67-rated enclosure withstands harsh weather, dust, and impact.
• Ultra-Low Power Consumption (< 5 W): Ideal for extended field campaigns with minimal energy use.
• Precise Timing Synchronization (≤ 30 ns): Dual GPS and thermostatic crystal clock ensure timing integrity in all conditions.
• High Data Capacity & Fast Transfer: Built-in 64 GB storage with USB, WiFi, and Ethernet connectivity. -
Request QuoteBrand: GOLDGD-C1201 FULL HOLE IMAGING SYSTEM
Product Features:
- Panoramic borehole imaging that captures continuous, full circumferences images of the borehole walls revealing bedding planes, fractures, lithological contacts, and structural features with exceptional details.
- Digital video and still capture offering both real time video streaming and high-resolution still image recording for post analysis and reporting.
- Depth-synchronized logging that authentically correlates image data with precise depth measurements for accurate geological interpretation.
- Robust downhole camera suited for high temperature, high pressure, and corrosion.
-
Request QuoteBrand: GOLDGDP-3D WIRELESS DIGITAL INCLINOMETER
Key Features
- Wireless and Bluetooth connectivity – enables seamless data transmission and real-time monitoring without cumbersome cables, enhancing field efficiency and safety.
- 3D orientation sensing – equipped with three magnetometers and three accelerometers for full spatial awareness and high-resolution directional data.
- Magnetic multi-shot surveying – captures multiple orientation points in a single run, ideal for complex borehole trajectories.
- High precision and stability – it is engineered for consistent performance in non-magnetic and weak magnetic formations, minimizing distortion and drift.
- Portable and user-friendly – It has a compact design and an intuitive interface suitable for varied field conditions and rapid deployment.
-
Request QuoteBrand: GOLDGDQ-2D DIGITAL INCLINOMETER
Product Features:
- Digital Accuracy – captures real-time inclination and azimuth readings with high resolution and stability.
- Non-magnetic compatibility – Ideal for use in formations where magnetic interference compromises traditional compass-based tools.
- Portable and Field ready – Lightweight, rugged design with intuitive interface for rapid deployment in remote or challenging terrain.
- Multi-drilling adaptability – suitable for hydrological, geothermal, mineral exploration, and geotechnical boreholes.
- Data Logging and transfer – Integrated memory and USB connectivity for seamless data export and post-processing.
-
Request QuoteBrand: GOLDGDQ-2D GEOPHYSICAL BOREHOLE LOGGING EQUIPMENT
Product Features:
- High resolution sensors for resistivity, seismic, IP, and magnetic measurements.
- Borehole cameras and loggers for visual inspection and structural analysis
- Modular design compatible with various probe types and depths
- Rugged construction for field reliability in harsh environments
- Intuitive design software for data visualization, interpretation, and reporting
-
Select optionsBrand: GOLDGYGD-IV Rotary Borehole Inspection Cameras Price range: KShs 921,200.00 through KShs 1,162,000.00
Technical Sheet
- Imaging Chip: 1/3” color CCD, sensitivity 0.1Lux.
- Display: LCD, 12 inches, resolution 1024*768.
- Lens: Manually fine-tune the focus; the lens is 360 degrees horizontally, tilted 180 degrees to rotate, freely controlled and can stay in any position.
- Illumination Unit: front LED patch lamp beads, the brightness of the light source is adjustable in 8 levels.
Measurement Depth: 300M, 400M, 500M, 600M, 800M, 1000M - Storage Unit: U Disk.
- Probe: Panorama/ rotation can be replaced at will, 40-120mm.
- Working Voltage: AC 220V50Hz.
- The tensile strength of the cable is 250kg.
- The maximum pressure of the probe is not less than 15Mpa.
-
Request QuoteBrand: GOLDGYGD-V PUSH ROD INSPECTION CAMERA
Product Features:
- High resolution camera head for detailed visuals.
- Flexible push rod system allowing navigation through narrow and curved pipes.
- Waterproof and corrosion resistant ensuring reliable performance in tough conditions.
- Real-time video and image capture
- Distance counter and depth indicator that tracks insertion length for accurate location mapping
-
HQ Core Drilling ToolsRequest Quote
Key Specifications
- HQ heads
- HQ bits
- Core lifters
- Core lifter cases
- Stop rings
- Reamer shells
