FDX 600 Core Drilling Rig
- (¥) CNY
- (UShs) UGX
- ($) USD
Key Specifications
- BTW Drilling Capability: 650 m
- NTW Drilling Capability: 600 m
- HTW Drilling Capability: 300 m
- Maximum Powerhead Torque: 1,600 N·m
- Maximum Powerhead Speed: 1,400 rpm
- Lifting Force: 16 T
- Propulsive Force: 8 T
- Engine: Yuchai 91 kW
- Drilling Angle: 45–90°
- Mounting: Rubber-track crawler
- Operating Weight: 5.7 T
The FDX-600 takes core drilling capability to 600 metres in NTW drilling, giving professional drilling contractors greater depth capacity while maintaining a compact hydraulic platform. Its 91 kW Yuchai engine, 1,600 N·m maximum torque, and 16-ton lifting force provide the capability needed for deeper core drilling operations. The rubber-track configuration also supports mobility across demanding field sites.
Built for the Job
- Cooling method: Water cooling
- Feed stroke: 2 m (optional)
- Winch rope capacity: 800 m
- Winch lifting force: 15 kN
- Hoisting speed: 110 m/min
- Wire rope diameter: 6 mm
- Overall height: 7 m
- Compensation stroke: 900 mm
- Gripper: BQ / NQ / HQ / PQ
- Gradeability: 30°
- Maximum travel speed: 3 km/h
- Mud pump: BW90
- Working dimensions: 4100 × 1900 × 7000 mm
- Transport dimensions: 4500 × 1900 × 2400 mm
